E-flite Mini Edge 3D ARF - Manual (Page 18)

18
Wing Installation
Required Parts
Fuselage Wing (right and left)
Wing tube #4 washer (silver) (2)
4-40 x 1/2" socket head screw (2)
Hex wrench: 3/32"
 1. Slide the wing tube into a wing panel.
 2. Remove the hatch from the fuselage. Slide the wing
panel with tube into position on the fuselage.
 3. Slide the remaining wing panel into position. Secure
the panels using 4-40 x 1/2" socket head screws with
#4 washers (silver) using a 3/32" hex wrench.
