Specifications
Supply Voltage and Current
62 x 62 Models: Infrared — 24V dc @ 100 mA max.
80 x 80 Models: 24V dc @ 250 mA max.
All other colors — 24V dc @ 130 mA max.
Connections
PVC-jacketed 3-conductor 2 m (6.5') or 9 m (30') at-
tached cable
Construction
Low-carbon steel with black zinc plating, acrylic win-
dow
Light Source
LED, see Models table above for wave lengths
Illumination
High-intensity ring light
Useful Life
10,000 hours (LED ON time). When operated within
specifications, output will decrease less than 30% after
10,000 hours and less than 50% (less than 40% for red
and IR models) after 20,000 hours.
Operating Conditions
Temperature: 0° to +50° C (+32° to 122° F)
Relative humidity: 90% at 50° C (non-condensing)
max.
Cleaning Instructions. Regularly remove any dust, dirt, or fingerprints from the light source.
1. Blow off dust using anti-static compressed air.
2. If necessary, use a lens cloth and lens cleaner or window cleaner to wipe off remaining debris. Do not use any other chemicals for
cleaning.
Dimensions
62 x 62 mm Models
33.3 mm
(1.31")
66.7 mm
(2.63")
66.7 mm
(2.63")
Ø 39.1 mm
(1.54") 104.1 mm
(4.10")
6.24 mm
(0.25")
58.2 mm
(2.30")
80 x 80 mm Models
86.1 mm
(3.40")
43.7 mm
(1.72")
86.1 mm
(3.40")
Ø 45.7 mm
(1.80") 109.9 mm
(4.33")
2 X 6.4 mm
(0.25")
58.4 mm
(2.30")
LED..R..W Series Ring Lights
