Machine Safety Switches –
SI-LS31H Series
P/N 50165 rev. D
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Dimensions
Accessories
Cable Glands
Size
Model
Used with
Switch Models
For Cable
Diameters
Dimensions
M20 x 1.5
Plastic
SI-QS-CGM0
All
5.0 to 12.0 mm
(0.20" to 0.47")
M20 x 1.5
25.0 mm
(0.98")
37.0 mm
(1.46")
Replacement Parts
Size
Model*
Used with
Switch Models
Thread
Conversion
Dimensions
½"-14 NPT
Plastic
Conduit Adapter
SI-QS-M0
All
M20 x 1.5 to
½"-14 NPT
25.0 mm
(0.98")
M20 x 1.5
24.0 mm
(0.94")
1/2"-14 NPT
Internal Thread
*NOTE: One conduit adapter is supplied with each switch.
22.0 mm
(0.87")
4.0 mm
(0.16")
62.0 mm
(2.44")
20.0 mm
(0.79")
5.1 mm
(0.20")
SI-LS31HGRD
SI-LS31HGLD
20.0 mm
(0.79")
31.0 mm
(1.22")
8.0 mm
(0.31")
ø 4.2 mm
(0.17")(2)
30.5 mm
(1.20")
70.0 mm
(2.76")
10.0 mm
(0.39")
2.5 mm
(0.10")
45 mm
(1.77")
93.5 mm
(3.68")
SISD1O05.eps
Slot for opening
cover to wiring chamber
(Use flat-blade screwdriver
and twist to open).
M20 x 1.5
(0.06")
1/2"-14 NPT
Adapter is Supplied
22.0 mm
(0.87")
4.0 mm
(0.16")
62.0 mm
(2.44")
160.0 mm
(8.30")
20.0 mm
(0.79")
5.1 mm
(0.20")
20.0 mm
(0.79")
31.0 mm
(1.22")
8.0 mm
(0.31")
ø 4.2 mm
(0.17") (2)
30.5 mm
(1.20")
70.0 mm
(2.76")
10.0 mm
(0.39")
2.5 mm
(0.10")
45.0 mm
(1.77")
Slot for opening
cover to wiring chamber
(Use flat-blade screwdriver
and twist to open).
M20 x 1.5
(0.06")
1/2"-14 NPT
Adapter is Supplied
Models SI-LS31HGRD/HGRE and HGLD/HGLE
Model SI-LS31HGD/HGE
