Connect the Camera
1. Push the camera cable’s round connector through the black grommet in the back of
the enclosure housing.
2. Connect the cable to the camera, but do not install the enclosure housing now.
3. Power up the camera.
4. Adjust horizontal aim using the mounting screws on the base (or straight bracket, if
used).
5. If right-angle bracket is not used, adjust vertical aim on the camera bracket.
If right-angle bracket is used, tighten screws in center of camera bracket slots and
use the vertical face of the right-angle bracket for adjustment.
6. Adjust the lens focus and aperture.
7. Verify that the front of the lens does not extend past the front edge of the base;
adjust camera bracket on base, if needed.
Assemble the Enclosure
1. Verify that there are no smudges on the window (especially on the inside) that could
cause imaging problems. (The window can be cleaned with standard glass cleaner
and a soft, non-abrasive cloth.)
2. Place the enclosure housing over the camera so the housing’s front end cap wraps
around the base’s front edge. Push the housing back until it clears the rear of the
base and drops down.
3. Reinstall the five screws.
Damaged Window Replacement
1. Remove the (4) Phillips screws on the sides of the end cap.
2. Remove the end cap with window and gasket.
3. Place the new window in the end cap and place gasket on top (it will be between the
window and the enclosure housing).
4. Place the end cap assembly onto housing and push down to compress gasket. Hold
down while reinserting (4) screws.
5. Tighten screws.
Specifications
Environmental Rating NEMA 1, IEC IP40
Construction
Enclosure: 20 gauge cold rolled steel with clear zinc plate,
including edges
Screws and nuts: 18-8 stainless steel
Gasket: Cellular urethane foam
Window: Model PPE-G: Glass;
Model PPE-P: Polycarbonate
Cord Grommet: 6/6 Nylon and Buna/N Nitrile
