SureCross™ DX80K Wireless Configured Kit
Specifications
Many of the DX80 parameters are configurable. The values in the tables represent factory defaults unless otherwise noted.
General
Power*
Gateway: +10 to 30V dc (For European applications: +10 to 24V dc, ± 10%)
Node: Internal battery
Power Consumption Less than 1.4 W (60 mA) at 24V dc
Mounting #10 or M5 (M5 hardware included)
M5 fasteners – Max. Tightening Torque 0.56 N•m (5 in•lbf)
Case Material Polycarbonate
Weight 0.26 kg (0.57 lb.)
Indicators Two LED, bi-color
Switches Two Push Buttons
Display Six Character LCD
External Cable Glands Four PG-7 type, One 1/2 NPT type
Cable Glands, Max Tightening Torque 0.56 N•m (5 in•lbf)
* For European applications, power the DX80 from a Limited Power Source as defined in EN 60950-1.
Radio 900 MHz 2.4 GHz
Range, with standard 2 dB antenna* Up to 4.8 kilometers (3 miles) Up to 3.2 kilometers (2 miles)
Frequency 902 to 928 MHz ISM band 2.4 to 2.4835 GHz ISM Band
Transmit Power 21 dBm Conducted 18 dBm Conducted, ≤ 20 dBm EIRP
Spread Spectrum Technology FHSS (Frequency Hopping Spread Spectrum) FHSS (Frequency Hopping Spread Spectrum)
Antenna Connector Ext. Reverse Polarity SMA - 50 Ohms Ext. Reverse Polarity SMA - 50 Ohms
Antenna - Max Tightening Torque 0.45 N•m (4 in•lbf) 0.45 N•m (4 in•lbf)
Link Timeout Configurable, up to 2 minutes Configurable, up to 2 minutes
* The range depends on the environment and line of sight. High-gain antennas are available to increase the range.
Inputs
Discrete Inputs Six Sourcing (Gateway)
Discrete Input Rating 3 mA max current at 30V dc
Discrete Input Sample Rate 62.5 milliseconds
Discrete Input Report Rate On Change of State
Discrete Input ON Condition Greater than 8V
Discrete Input OFF Condition Less than 5V
Outputs
Discrete Outputs Six Sourcing (Gateway)
Discrete Output Rating
100 mA max current at 30V dc, ON-State Saturation: Less than 2V at 100 mA, OFF-state Leakage:
Less than 10 µA
Discrete Output Update Rate 62.5 milliseconds
Discrete Output ON Condition Supply minus 2V
Discrete Output OFF Condition Less than 2V
Discrete Output State Following Timeout De-energized (OFF)
