MANUALLY CONFIGURING NETWORK SETTINGS
69
Set up the computer that is connected to the cable or DSL modem FIRST using
these steps. You can also use these steps to add computers to your Router after
the Router has been set up to connect to the Internet.
Manually Configuring Network Settings in Mac OS up to 9.x
1. Pull down the Apple menu. Select “Control Panels” and select “TCP/IP”.
2. You will see the TCP/IP control panel. Select “Ethernet Built-In” or
“Ethernet” in the “Connect via:” drop-down menu (1).
3. Next to “Configure” (2), if “Manually” is selected, your Router will need
to be set up for a static IP connection type. Write the address
information in the table below. You will need to enter this information
into the Router.
4. If not already set, at “Configure:”, choose “Using DHCP Server”. This will
tell the computer to obtain an IP address from the Router.
(1)
(2)
