KNOWING YOUR BELKIN ROUTER
4.
WAN Status LED
This LED lights in GREEN to indicate that your modem is connected
properly to the Router. It blinks rapidly when information is being sent
over the port between the Router and the modem.
OFF
No WAN Link
Solid Green
Good WAN Link
Blinking Green
WAN Activity
(1)
(2)
(3)
(4)
(6)
(7)
(8)
(9)
5
(5)
(10)
Rear Panel
Front Panel
Port Number
Labeling
Antenna
P74122_F5D6231-4_man.qxd 11/6/02 1:03 PM Page 5
