Metrohm 858 Professional Sample Processor - Manual (Page 33)

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
858 Professional Sample Processor ￭￭￭￭￭￭￭￭ 25
3.8 Mounting the sample tube
Needles made of zirconium oxide or PEEK can be used for removing sam-
ples.
Warning
When a sample tube 6.1835.050 or a blunt PEEK needle is used, no
stopper is permitted to be used on the sample vessels. These stoppers
cannot be penetrated by such needles. The needle could become dam-
aged if this is attempted! Perforated stoppers can be used with dou-
ble-bevel needles.
1
2
3
4
5
6
Figure 23 Mounting the needle
1 PTFE capillary
6.1803.070 or 6.1831.050 / 6.1831.060 /
6.1831.080 2 PEEK pressure screw
6.2744.010
