2 Overview of the instrument

858 Professional Sample Processor

￭￭￭￭￭￭￭￭

9

2.2

Rear

USB 2

USB 1

Contr.

MSB 1

MSB 2

MSB 3

Made by Metrohm
Herisau Switzerland

P: 115W U: 100 - 240 V f: 50 - 60 Hz

WARNING - Fire Hazard -

For continued protection replace only

with the same type and rating of fuse

Swing

Head

Ext.

Pump 1

Ext.

Pump 2

Nr

.

1

2

4

5

3

Figure 2

Rear 858 Professional Sample Processor

1

Pump connectors
M8 connector for external pumps

2

Stirrer connector
For rod stirrer and 741 Magnetic Stirrer

3

Connector strip
Details (see Chapter 2.3, page 10)

4

Warning symbols
(see Chapter 1.6.3, page 5)

5

786 Swing Head connector
