©2012 DJI Innovations. All Rights Reserved. 27 |
Product Specifications
General
Built-In Functions  Autopilot
 Tail Gyro
 Engine Governor for gas power
 Flybarless
 Auto Hover or Level Fail Safe
 Semi Auto Takeoff & Landing
Peripheral
Supported Helicopter Types  Electric
 Internal combustion
Supported Swashplate Types  Normal
 Three Servo 120°/140°/90°
 Four Servo 90°
Supported Servo output  Rudder channel: Analog 50Hz
 Rudder channel: Digital 333-560Hz (760us-1520us)
 Other channels: Follow on your receiver output
Recommended Transmitter PCM or 2.4GHz with minimum 7 channels and failed-safe
function available on all channels.
Recommended Power Supply DC 4.8
～8.4V (Not to exceed MAX operating voltage of servo
motor); >1500 mAh capacity, Discharge current more than 5C;
7.5A to 15A external BEC, servos dependent
Assistant Software System Requirement Windows XP SP3 / 7
Electrical & Mechanical
Power Consumption MAX 5W (0.9A@5V, [email protected], [email protected], 0.4A@8V)
Operating Temperature -5°C to +60°C
Total Weight <= 150g (overall)
Dimensions  MC: 51.2mm x 38.0mm x 15.3mm
Lite GPS/Compass is NOT in WKH Lite  IMU: 41.4mm x 31.1mm x 27.8mm
 GPS & Compass: 50mm (diameter) x 9mm
 LED Indicator: 25mm x 25mm x 7mm
Flight Performance (can be effected by mechanical performance and payloads)
Hovering Accuracy (GPS Mode)  Vertical: ± 0.5m
Lite NOT with WKH Lite  Horizontal: ± 1m
Maximum Wind Resistance <8m/s (17.9mph / 28.8km/h)
Forward / Backward Speed ±72km/h (44.74mph)
Left / Right Speed ±56.7km/h (35.77mph)
