CALIPER INSTRUCTIONS
Operations
ON/OFF button
• Press ON/OFF button at any position when the power is off, this Caliper will be ready to work and display the measuring value
• Press ON/OFF at any position when the power is on, this Caliper will switch off
ABS/INC button
• Press ABS button in absolute mode (without “ABS” ), this Caliper is ready for absolute measurement
• Press ABS button in relative mode (with “ABS” displaying), this Caliper is ready for relative measurement and simultaneously
displays “ABS”, showing relative mode
• Press ABS at any position for relative/absolute measurement interchange
ZERO button
• In relative mode, press ZERO button to set the current point to zero and this Caliper will display zero
• In absolute mode, press ZERO button to set the current point to the preset value and this Caliper will display this value
mm/in button
• Press mm/in button at any position for metric/inch conversion
SET button and Internal Measuring (Easy one touch set)
• For presetting a starting point (the value has been preset to zero in the factory)
• With each one press on this button at any position, the current point is set to the preset value and displays on the LCD.
The details are as the follows:
Number of
Times Pressed
Preset Value
1 12.7mm / 0.5" optional measuring
2 20.32mm / 0.8" optional measuring
3 25.4mm / 1" for optional measuring
4 50.8mm / 2" for optional measuring
5 76.2mm / 3" for optional measuring
6 101.6mm / 4" for optional measuring
7 127mm / 5" for optional measuring
8 152.4mm / 6" for optional measuring
g 10mm / 0.3935" for optional measuring
10 20mm / 0.7870" for internal measuring of 600mm calipers
11 25mm / 0.9840" for optional measuring
12 50mm / 1.9685" for optional measuring
13 0 standard, after internal and optional
measuring, please set for normal measuring
• The process is circulative. The preset value is held even after powering off
HOLD button
• Press “H” button at any position, this Caliper will hold the value as before and display “H” on the LCD.
The data will not change even if you move the slider
• Press “H” button once again to release hold state (no character “H” displays), then this Caliper displays the measured value
Restart this Caliper after powering off by pressing ON/OFF button, it will keep the last state (mm/in, ABS/INC,SET).
