DIGITRONIC MICROMETER INSTRUCTIONS
For more information visit www.moore-and-wright.com Partners in Precision
4.2 ABS/INC - UNIT Key
• Press and release: Absolute and relative measuring mode conversion; ‘INC’ sign
displayed on LCD in relative measuring mode. No sign displayed on LCD in absolute
measuring mode
• Press and hold (2 sec. or more): metric/inch conversion; ‘in’ sign displayed on LCD for
inch, otherwise mm
5. Power
• Use a CR2032 Lithium battery and replace the battery when the display begins to dim or
the data on the LCD flashes
• If the micrometer is not used for five minutes the power will automatically shut off.
Power off the micrometer by pressing the ‘On/Off – SET‘ key to save the battery when
not in use
6. General Specifications
• Measuring force: 5-10N
• Operating temperature: 0-40°C • Power consumption: ≤20µA
• Storage temperature: -20-60°C
7. Precautions
• Do not subject the instrument to blows or shock. Do not drop it or apply excessive force
• Do not disassemble the instrument
• Do not press the keys with a pointed object
• Do not use or store the instrument under direct sunlight or in an excessively hot or
cold area
• Avoid exposing the instrument to strong magnetic fields and high voltage
• Use a soft cloth to clean the instrument. Never use organic solvents such as acetone or
benzene to clean. Alcohol may be used
• Clean measuring faces before use
• If the instrument is to be stored or left unused for extended periods, remove the battery
8. Troubleshooting
Problem(s) Cause(s) Solution(s)
Measuring data
incorrect Dirty measuring faces Preset
data is not correct Clean measuring faces Inspect
preset data and reset it
No display on LCD Battery voltage under 2.7v
Battery is not properly set Reset battery
(remove for 3 minutes)
Display confused or
remains blank Battery voltage under 2.7v Replace battery
