Page 56

44
Burst Average Power
Power Range
2.6 – 100 W average
Burst Width
1 μs – 5 ms
Repetition Rate, Min
5 Hz (with 12 dB Peak/Avg ratio)
Duty Cycle (D)**
0.02 to 1 (D = Burst Width / Period)
Measurement Uncert. ± (6% of reading + 166/D mW)
a
a. Above 35 °C or below 15 °C add 3%
** Duty Cycle and CCDF read out dependent on display
method.
Crest Factor
RF Power Range
100 mW to 100 W average, 2.6 W
minimum peak
Measurement
Uncert.
Linear sum of peak and average power
uncertainty
Complementary Cumulative Distribution Function
(CCDF)
Measurement Range*
0.1 – 100%
Measurement Uncert.
± 2%
Threshold Level Range 2.6 W to 260 W peak
Level Set Accuracy
As peak power uncert. + 2%
* Duty Cycle and CCDF read out dependent on display
method.
