Chapter 2
Installation
Connections
5012D
5016D
5017D
5018D
5019D
5012A
Note:
VPM1
ONLY for Serial
Connections.
USB Only
USB & Serial
Serial Only
WARNING
Never attempt to connect or disconnect RF equipment from
the transmission line while RF power is being applied.
Leaking RF energy is a potential health hazard.
To connect the WPS to the Digital Power Meter, use the serial
cable provided. Connect the male end of the cable to the DPM
and the female end to the WPS. A separate power supply for
the WPS is not required when using a DPM.
Note:
Connect the WPS to the RF line so that the
arrow on the sensor points towards the load.
There are two ways to connect the WPS to a PC running the
Virtual Power Meter Software:
