5016D Specifications
Sensor Characteristics
Frequency Range
350 MHz to 4 GHz
RF Power Range
25 mW – 25 W Average, 1W to 60 W
peak
Maximum Power
Impedance, Nominal
50 ohms
Insertion Loss, Max:
0.35 – 1 GHz
1 – 4 GHz
0.05 dB
0.1 dB
Input VSWR, Max:
0.35 – 2.5 GHz
2.5 – 4 GHz
1.05
1.10
Directivity, Min:
0.35 – 3 GHz
3 – 4 GHz
30 dB
28 dB
RF Connectors
N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no
parity, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity, 8 data bits, 1 stop bit
USB 1.1 interface
Power Supply:
DPM
USB Port
DC Connector
From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA
Data Logging
In VPM software
