Page 29

17
Chapter 4
Specifcations
5012D Specifications
Sensor Characteristics
Frequency Range
350 MHz to 4 GHz
RF Power Range
0.15 W to 150 W average, 4W to 400
W peak
Maximum Power
See Figure
19.
Impedance, Nominal 50 ohms
Insertion Loss, Max:
0.35 – 1 GHz
1 – 4 GHz
0.05 dB
0.1 dB
Input VSWR, Max:
0.35 – 2.5 GHz
2.5 – 4 GHz
1.05
1.10
Directivity, Min:
0.35 – 3 GHz
3 – 4 GHz
30 dB
28 dB
RF Connectors
N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, EIA-232, 9600 Baud, no
parity, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity, 8 data bits, 1 stop bit
USB 1.1 interface
