35
5018D Specifications
Sensor Characteristics
Frequency Range 150 MHz to 4.0 GHz
RF Power Range 100 mW to 25 W average,
60 W peak
Maximum Power See Figure 10 on page 25.
Impedance, Nominal 50 ohms
Insertion Loss, Max:
150 – 1000 MHz
1000 – 4000 MHz
0.05 dB from 0.15 to 1.0 GHz
0.01 dB from 1.0 to 4 GHz
Input VSWR, Max:
150 – 2500 MHz
2500 – 4000 MHz
1.05 from 0.15 to 2.5 GHz
1.10 dB from 2.5 to 4 GHz
Directivity, Min:
150 – 3000 MHz
3000 – 4000 MHz
30 dB
28 dB
RF Connectors N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no
parity, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity, 8 data bits, 1 stop bit
USB 1.1 interface
