36

Average Power

RF Power Range

25 mW – 25 W

Peak/Average Ratio, Max 12 dB

Measurement Uncert.

± (4% of reading + 0.008 mW)

a

a. Above 35 °C or below 15 °C add 3%

Match Measurement

Measurement Range:

Return Loss
Rho (

)

VSWR


0 to 23 dB
0.07 to 1.0
1.15 to 99.9

Forward Power, Min

0.1 W

Measurement Uncert.

See Figure

11 on page

30.

Power Supply:

DPM
USB Port
DC Connector


From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA

Data Logging

In VPM software
