Maintenance
45
Model 8638B Load — 8738-101 - 3-1/8" Unflanged Connector - 50 ohms
For all Models
Optional Items
DESCRIPTION QTY PART NUMBER
Center Conductor Assembly 1 8738-003
Resistor Fitting 1 8731-017
Center Conductor 3/8-16" Hex Nut 1 Standard
3/8" Split Lockwasher 1 Standard
Center Conductor 1 8738-005
Outer Conductor Assembly 1 8738-002
DESCRIPTION QTY PART NUMBER
Resistor Spacer Ring 1 8731-008
1/4-20 x 5/8" Hex Head Cap Screw 6 1121-1008-00
DESCRIPTION QTY PART NUMBER
Ethylene glycol 1 gal 5-1134-3
Repair and Replacement Kit, P/N
Consists of:
Coolant and Container Assy. (8630-197),
50 ohm resistor (8731-031-1), and
instruction sheet (921-8630-196).
1 8630-196
