Bird AT-500 Antenna Tester
46
7. Be sure P2 is connected and the shock strips are
still in place.
8. Place the back cover over the front cover making
sure it is properly seated.
9. Replace the six screws.
10. Run the battery test on page 42 of this section.
Fuse Replacement
Note:
Follow the steps outlined in Battery
Replacement replacing the fuse where replac-
ing the batteries is indicated.
Figure 17 Battery / Fuse Replacement
CAUTION
Replace with only the same type and rating fuse.
315mA 250V
P2 Battery Connector Fuse Shock Strips
