Measure Match
23
Figure 10 Manual Scaling Single Frequency Model
Sweep Type-Single Hold vs. Continuous
Continuous sweep continually sweeps the selected fre-
quency band updating the measured value with each
sweep. An asterisk (*) is blinking on the left side of the
display to indicate sweep rate. The single hold mode
will freeze a trace on the display and hold is displayed
on the right. Holding a trace is also helpful before sav-
ing the trace, (more about saving traces under that
heading later in this section).
Swept Frequency
Select Frequency Band
There are two options for selecting the frequency band.
The first is simply to enter the start and stop frequen-
cies. The second is to enter a span frequency, which is
the desired width of the band, and a center frequency,
that will be used as the center of the band.
1. Press the MENU key.
2. Press the SWEPT FREQ key.
3. Press the BAND key.
4. Depending on desired method press either Start
Stop MHz or Center MHz:
VSWR
1.0 5.0
1.35
69.00 MHz
Freq
Mhz
Units Manual
Scale
Auto
Scale
Audio
Off
