KUMO v3.1 www.aja.com 21
IMPORTANT: When using KUMO in a DHCP or Static IP addressed network, it is best to select and
maintain a consistent network scheme. If you use a mix of DHCP and Static IP addresses,
inconsistent performance can result. The most stable operation is achieved when all IP
addressing is either DHCP or Static
Setup and Control from a Browser on Mac OSX
The two easiest methods to set up and control a KUMO router system from a Mac are:
• Setup and Control from a Safari Browser on Mac OSX using Bonjour
• Setup and Control from a Browser on Mac OSX using a Static IP Address
Safari Browser
Using Bonjour
This method was covered earlier in this chapter. See “Mac Configuration with Safari
Browser Using Bonjour” on page 15 .
Safari Browser: Type
in KUMO Static IP
Address
KUMO offers a factory default static IP address. The default static IP address is temporary
and is intended only to allow an initial connection. Once you’ve connected using the
static IP, you can then enter a desired network configuration using KUMO's Network tab.
NOTE: The default static address is temporary and will be disabled the next time KUMO restarts. Any
changes in the Network configuration will be saved upon restart.
1. Set the KUMO to its factory default IP address. See “KUMO Temporary Static IP Address”
on page 16 for this procedure.
2. Configure your computer to talk on the 192.168.101.X subnet as shown below:
IMPORTANT: First record existing TCP-IP settings so that you can return your computer to normal
operation after this procedure.
A. Go to your System Preferences>Network and select Ethernet and Configure:
Manually.
