Chapter
5
Wire the LX-Series Linear Motor
Introduction This section shows you how to wire your LX-Series linear motor.
Connect the Linear Motor
Coil
Use the following procedure to connect your linear motor, catalog number
LX xxxxxxxx11x.
1. Wire your encoder to the connector by using the Encoder Connector Kit,
catalog number LDC-ENC-CNCT, and the connector data on page 33 .
2. Connect your encoder to the encoder connector on the Hall effect
module.
3. Attach the motor feedback and power cables.
a. If using a quick-connect connector, remove the o-ring before making
the connection.
Topic Page
Connect the Linear Motor Coil 35
Signal and Wire Definitions for Flying Lead Components 37
Making Your Own Extension Cables 39
Mounting and Wiring Two Identical Coils in Tandem 40
ATTENTION: Be sure that cables are installed and restrained to
prevent uneven tension or flexing at the cable connectors. Use the
Bulk Head Connector Kit, catalog number LDC-BULK-HD, for
mounting these connectors.
Excessive and uneven lateral force at the cable connectors may
result in the connector’s environmental seal opening and closing
as the cable flexes.
Failure to observe these safety precautions could result in damage
to the motor and its components.
ATTENTION: Do not connect or disconnect the motor feedback
cable or the power cable while power is applied. It may result in
unexpected motion or cause damage to the components.
