AVAILABLE SPARES
For special sized sensor mats, refer to the model no. printed on the label.
After replacing any parts the inspection and test shown at 8.2 must be carried out with special attention
given to those parts replaced.
WARNING
After maintenance or repair operations it is important that all edging trims, fastenings and cable
protection are correctly refitted. Failure to do this or the use of non approved parts or modifications may
result in the mat system failing to achieve its specified performance.
8.7 SERVICE
For service and assistance please contact the supplier.
Size Model No.
Perimeter trim Specify length MGT 3010
Twp piece perimeter trim Specify length MGT 3011
(with cable trunk)
Uniting trim
Specify length MGT 3020
Protective wire guide Specify length MGT 3030
Mat Control unit MGCP1
MGCS1
MGCD1
MGCSM1
Remote indication unit for use with MGCD1 MGRID1
System Spares Kit Description Part No.
2 Fuses 500mA(T) TR5
4 Butt splice connectors 108433
4 Pin crimps
1 Push button bulb
Standard sIzes Model No.
Sensor mat 500mm x 500mm MGM 1010
Sensor mat 750mm x 500mm MGM 1510
Sensor mat 1000mm x 500mm MGM 2010
Sensor mat 500mm x 1500mm MGM 1030
Sensor mat 750mm x 750mm MGM 1515
Sensor mat 1000mm x 750mm MGM 2015
Sensor mat 750mm x 1500mm MGM 1530
Sensor mat 1000mm x 1000mm MGM 2020
Sensor mat 1000mm x 1250mm MGM 2025
Sensor mat 1000mm x 1500mm MGM 2030
40
length Catalog No.
Standard Perimeter Trim 2M 440F-T3210
Standard Perimeter Trim 3M 440F-T3310
Standard Perimeter Trim 5M 440F-T3510
External Corner Standard Perimeter Trim - 440F-T3012
Internal Corner Standard Perimeter Trim - 440F-T3013
Perimeter Trim with Cable Channel 2M 440F-T3211
Perimeter Trim with Cable Channel 4M 440F-T3411
External Corner Perimeter Trim
with Cable Channel - 440F-T3014
Internal Corner Perimeter Trim
with Cable Channel - 440F-T3015
Active Uniting Trim - 440F-T3020
Vinyl Wire Guide - 440F-T3230
Mat Controllers - 440F-C4000P
- 440F-C4000S
- 440F-C4000D
- 440F-C28013
Fuse, 500 mA - 440R-A31562
Shorting Plug - 440F-A28639
Mat Size Safety Mat Standard Perimeter
Trim Kit
millimetres inches Catalog No. Catalogue No.
500 x 500 19.7 x 19.7 440F-M1010BYNN 440F-T1010
500 x 600 19.7 x 23.6 440F-M1012BYNN 440F-T1012
500 x 900 19.7 x 35.4 440F-M1018BYNN 440F-T1018
500 x 1000 19.7 x 39.4 440F-M1020BYNN 440F-T1020
500 x 1200 19.7 x 47.2 440F-M1024BYNN 440F-T1024
500 x 1500 19.7 x 59.1 440F-M1030BYNN 440F-T1030
600 x 600 23.6 x 23.6 440F-M1212BYNN 440F-T1212
600 x 750 23.6 x 29.5 440F-M1215BYNN 440F-T1215
600 x 900 23.6 x 35.4 440F-M1218BYNN 440F-T1218
600 x 1000 23.6 x 39.4 440F-M1220BYNN 440F-T1220
600 x 1200 23.6 x 47.2 440F-M1224BYNN 440F-T1224
600 x 1500 23.6 x 59.1 440F-M1230BYNN 440F-T1230
750 x 500 29.5 x 19.7 440F-M1510BYNN 440F-T1510
750 x 750 29.5 x 29.5 440F-M1515BYNN 440F-T1515
750 x 1500 29.5 x 59.1 440F-M1530BYNN 440F-T1530
800 x 600 31.5 x 23.6 440F-M1612BYNN 440F-T1612
800 x 750 31.5 x 29.5 440F-M1615BYNN 440F-T1615
800 x 900 31.5 x 35.4 440F-M1618BYNN 440F-T1618
800 x 1000 31.5 x 39.4 440F-M1620BYNN 440F-T1620
800 x 1200 31.5 x 47.2 440F-M1624BYNN 440F-T1624
800 x 1500 31.5 x 59.1 440F-M1630BYNN 440F-T1630
900 x 900 35.4 x 35.4 440F-M1818BYNN 440F-T1818
900 x 1000 35.4 x 39.4 440F-M1820BYNN 440F-T1820
900 x 1200 35.4 x 47.2 440F-M1824BYNN 440F-T1824
900 x 1500 35.4 x 59.1 440F-M1830BYNN 440F-T1830
1000 x 750 39.4 x 29.5 440F-M2015BYNN 440F-T2015
1000 x 1000 39.4 x 39.4 440F-M2020BYNN 440F-T2020
1000 x 1200 39.4 x 47.2 440F-M2024BYNN 440F-T2024
1000 x 1250 39.4 x 49.2 440F-M2025BYNN 440F-T2025
1000 x 1500 39.4 x 59.1 440F-M2030BYNN 440F-T2030
