F-2 Diagnositics, Troubleshooting, and Start-Up Guidelines
LED I/O FLT When lit, indicates communication between a Flex I/O module and
the PMI Regulator has been disrupted, or that Flex I/O is configured
but is not plugged in.
Related Reg/Bit 203/1203 bit 13
WRN_I/O@ Flex I/O Communication Error
LED FDBK OK When lit, indicates that the Resolver & Drive I/O board is receiving
feedback from the resolver and that no resolver feedback faults have
been detected.
Related Reg/Bit 202/1202 bit 8
FLT_TBW@ Resolver Feedback Broken Wire
LED RPI When lit, indicates the run permissive input signal has been
detected.
Related Reg/Bit 201/1201 bit 0
RPI@ RPI Input Status
LED MCR When lit, indicates that the MCR output signal is being driven on.
LED AUX IN1 When lit, indicates the presence of a 115V signal on this input.
Related Reg/Bit 201/1201 bit 1
M_FDBK@ Aux Input 1/MFDBK Status
LED AUX IN2 When lit, indicates the presence of a 115V signal on this input.
Related Reg/Bit 201/1201 bit 2
AUX_IN2@ Aux Input 2 Status
LED AUX IN3 When lit, indicates the presence of a 115V signal on this input.
Related Reg/Bit 201/1201 bit 3
AUX_IN3@ Aux Input 3 Status
LED AUX IN4 When lit, indicates the presence of a 115V signal on this input.
Related Reg/Bit 201/1201 bit 4
AUX_IN4@ Aux Input 4 Status
LED AUX IN5 When lit, indicates the presence of a 115V signal on this input.
Related Reg/Bit 201/1201 bit 5
AUX_IN5@ Aux Input 5 Status
LED AUX OUT When lit, indicates the output signal has been turned on.
Related Reg/Bit 101/1101 bit 4
AUX_OUT@ Aux Output Status
Name Description
