Drive Fault Register A-3
Over Temperature Fault Bit 7
The Over Temperature Fault bit is set if the
thermistor in the Power Module detects a
temperature of 100° C or more. Hex Value: 0080H
Sug. Var. Name: FLT_OT@
Access: Read only
UDC Error Code: 1016
LED: P.M. FLT
Resolver Broken Wire Fault Bit 8
The Resolver Broken Wire Fault bit is set if a
sine or cosine signal from the resolver is
missing due to a broken wire or if the
resolver gain tunable (RES_GAN%) has
been set too low. Hex Value: 0100H
Sug. Var. Name: FLT_TBW@
Access: Read only
UDC Error Code: 1008
LED: FDBK OK
Resolver Fault Bit 9
The Resolver Fault bit is set if the fuse
blows on the Resolver & Drive I/O board.
This indicates the board has failed and must
be replaced. Hex Value: 0200H
Sug. Var. Name: FLT_RES@
Access: Read only
UDC Error Code: 1009
LED: N/A
Overspeed Fault Bit 10
The Over Speed Fault bit is set if the motor’s
velocity exceeds the value entered as the
Over Speed Trip (RPM) configuration
parameter. Hex Value: 0400H
Sug. Var. Name: FLT_OSP@
Access: Read only
UDC Error Code: 1010
LED: EXT FLT
Power Technology Fault Bit 11
The Power Technology Fault bit is set to
indicate a problem with the AC power
technology circuit on the PMI Regulator
motherboard. Hex Value: 0800H
Sug. Var. Name: FLT_PTM@
Access: Read only
UDC Error Code: 1011
LED: OK
Register 222/1222 provides additional diagnostics if this fault occurs.
PMI Regulator Bus Fault Bit 13
The PMI Regulator Bus Fault bit is set if the
Resolver & Drive I/O board or the AC power
technology circuit does not respond to
requests from the PMI Processor. This
indicates a hardware problem in the PMI
Regulator. Hex Value: 2000H
Sug. Var. Name: FLT_BUS@
Access: Read only
UDC Error Code: 1013
LED: N/A
