Rockwell Automation 2LW3000 LonWorks Communication Option Module for VTAC 7 Drives User Manual
Page 16
3-2
LonWorks Module for VTAC 7 Drives
20
20H41xx
20H42xx
3.5
25
25H41xx
25H42xx
25W21xx
3.5
30
30W21xx
3.4
30
30H41xx
30H42xx
3.5
40
40W21xx
3.4
40
40H41xx
40H42xx
3.5
50
50W21xx
3.4
50
50H41xx
50H42xx
3.5
60
60H41xx
60H42xx
3.5
60
60W21xx
3.4
75
75W21xx
3.4
75
75H41xx
75W41xx
3.4
100
100H21xx
3.4
100
100H41xx
100W41xx
3.4
125
125H41xx
125W41xx
3.4
150
150H41xx
150W41xx
3.4
200
200W41xx
3.4
200
200H41xx
3.6
250
250H41xx
3.6
300
300H41xx
3.6
350
350H41xx
3.6
400
400H41xx
3.6
Table 3.1 – Locating the Appropriate Installation Procedure (Continued)
Horsepower Rating
Drive Model Number
Use the Procedure in
Section …
