Getting Started 2-3
2.2 Installation Checklist
This section is designed to help experienced users start using the LonWorks module.
If you are unsure how to complete a step, refer to the referenced chapter
When to press service pin?
Step Action Refer to
❒ 1 Review the safety precautions for the
module. Throughout
this manual
❒ 2 Verify that the drive is properly
installed. VTAC 7 AC
Drive User
Manual
(D2-3372)
❒ 4 Install the module in the drive.
Verify that the drive and the network are
not powered. Then, connect the module
to the drive. Use the captive screws to
secure and ground the module to the
drive.
Chapter 3
❒ 5 Connect the drive to the network. Chapter 4
❒ 6 Apply power to the drive and
network.
Verify that the module and network are
installed correctly and then apply power
to them. The module receives power
from the drive and network.
Chapter 4
❒ 7 Program the drive for network
communication. Chapter 5
❒ 8 Install the drive as a node in the
network.
Use a network tool for LonWorks (such
as LonMaker) to install the drive as a
node in the network.
Instruction
manual for
LonWorks
installation
tool
