5-6 Serial Converter Module (MDCOMM-232)
5.4.1 Viewing DF1 Data
To view DF1 data:
Step 1. Access the parameters in the Serial Converter using a
configuration tool. Refer to section 4.1.
Step 2. Scroll through the DF1 parameters. Parameters 06
through 17 contain DF1 data. For a description of each
parameter, refer to Appendix B, Serial Converter
Parameters. Figure 5.4 shows DF1 data viewed in
HyperTerminal.
5.4.2 Clearing DF1 Counters
To clear DF1 counters:
Step 1. Access the parameters in the Serial Converter using a
configuration tool. Refer to section 4.1.
Step 2. Set the value of Clear DF1 Counts (06) to Clear Counts,
and then press Enter to clear the DF1 data. Figure 5.5
shows DF1 counters cleared in HyperTerminal.
Figure 5.4 – Viewing DF1 Data in HyperTerminal
Press the UP ARROW or DOWN ARROW key to scroll
through the parameter list. Press the LEFT ARROW or
RIGHT ARROW key to modify parameter values. Press
the ENTER key to save a new value.
7R> DF1 Packets Sent = 0
Figure 5.5 – Clearing DF1 Counters in HyperTerminal
Press the UP ARROW or DOWN ARROW key to scroll
through the parameter list. Press the LEFT ARROW or
RIGHT ARROW key to modify parameter values. Press
the ENTER key to save a new value.
6> Clear DF1 Counts = Clear Counts
