RDD-Series Rotary Direct Drive Bearingless Motor Installation Instructions 5
Publication RDB-IN002B-EN-P — February 2010
Required Tools
These tools are needed to install this product.
These additional tools are needed to remove this product.
Tools Required for Installation Value
Hex bit, 150 mm (6 in.) minimum length 6 mm
Torque wrench Capable of applying at least 65 N•m (50 lb•ft)
Screwdriver Phillips #2
Micrometer N/A
Straight edge
Caliper
Runout indicator
Cleaning cloth
Shaft key (provided)
Tools Required for Removal Value
M6 x 1 x 120 hex bolt or rod
(For RDB-B4103 motor only)
Qty 1
M10 and M12 hex bolts Qty 2 min
Flashlight N/A
Hammer
