Specifications
Max.
Armature HP Range HP Range
Current with 115 VAC with 230 VAC
Model (Amps DC) Applied Applied Style
DC3N-12D-00-010-AN† 10.0 1/8–1 1/4–2 Chassis
DC3N-12D-01-010-AN‡ 10.0 1/8–1 1/4–2 NEMA 1
DC3N-12D-4X-010-AN‡‡ 10.0 1/8–1 1/4–2 NEMA12/4/4X
† Double maximum armature current and horsepower when drive is mounted on heat sink
part number DC3N-HS-00.
‡ Double maximum armature current and horsepower when drive is mounted on heat sink
part number DC3N-HS-01.
‡‡ Indoor use only
Motor HP Rated AC Input DC Amature DC Armature
Line Amps KVA Voltage Current
1/4 4.5 0.5 90 2.7
2.6 0.6 180 1.4
1/3 5.9 0.7 90 3.5
3.1 0.7 180 1.8
1/2 7.8 0.9 90 5
3.7 0.8 180 1.3
3/4 10.6 1.2 90 7.6*
5.6 1.3 180 3.8
1 13 1.5 90 10*
7 1.6 180 5
1 1/2 -- -- -- --
10.1 2.3 180 7*
2 -- -- -- --
12 2.8 180 9.2*
* Heatsink required for operation above 5 amps. Use DC3N-HS-00 for chassis drives
and DC3N-HS-01 for NEMA 1 drives.
AC Line Voltage
115 VAC or 230 VAC ±10%, 50/60 Hz, single phase
Maximum Allowable Symmetrical AC Line Current 5000 Amps
Maximum AC Line Distribution kVA
115 VAC Input 25 kVA
230 VAC Input 50 kVA
Motor Armature Voltage
115 VAC Input 0–90 VDC
230 VAC Input 0–180 VDC
Adjustments and Application Data
Form Factor
1.37 at base speed
Service Factor 1
Maximum Current Load 150% for 1 minute
Speed Regulation 1% with 95% load change
