Operation – Rockwell Automation DC3N DC Drive User Guide, 1/4-2HP-115/230 VAC User Manual
Page 25
17
Figure 9. Voltage Switches
SW502
SW501
SW503
Operation
ATTENTION:
Change voltage switch settings only when the drive is
disconnected from AC line voltage. Make sure both switches are set to their
correct position. If the switches are improperly set to a lower voltage position,
the motor will not run at full voltage and may cause damage to the transformer.
If the switches are improperly set to a higher voltage position, the motor will
overspeed, which may cause motor damage, or result in bodily injury or loss of
life.
ƽ
