Adjustments and Application Data (cont.)
2 Specifications
Speed Range 60:1
Accel. Time Range
0–90 VDC Armature Voltage 0.5–17 seconds
0–180 VDC Armature Voltage 0.5–17 seconds
Decel. Time Range
0-90 VDC Armature Voltage 0.5–17 seconds
0–180 VDC Armature Voltage 0.5–17 seconds
Current Limit Overload Range 150%
Analog Input Voltage Range (must be isolated; S1 to S2)
for 0–90 VDC Armature Voltage 0–1.4 VDC
for 0–180 VDC Armature Voltage 0–2.8 VDC
Torque 150% of rated current
Input Impedance (S1 to S2) 100K ohms
Speed adjust potentiometer rating 10k ohm, 5W (5k ohms acceptable)
IR Drop Compensation (% of rated armature voltage) 0% to 15%
Service Conditions
Elevation
3300 ft (1000 m) max without derating**
Vibration 0.5G max (0–50 Hz)
0.1G max (>50 Hz)
Ambient Temperature Range
Enclosed drive 10°C–40°C
Chassis drive 10°C–55°C
Non-condensing Relative Humidity 0% to 95%
** Derate the current by 1% for every 300 ft (90m) above 3300 ft. (1000m), up to
10,000 ft (3000m)
Safety Certification
UL Listed Component
cUL Listed Component
CE Certificate of Compliance
