Add a PowerFlex 70 Drive to an RSLogix 5000 Project
In this chapter, you add a 20A-B4P2A0AYNNNC0 drive to an RSLogix 5000 project and
configure it. You also download the project to the controller so you can verify communication
with the drive.
Before You Begin
You must complete these tasks before using this chapter:
•
The tasks described in
Before Using This Publication on page 5
, including:
–
Prepare the Logix5000 control system hardware
–
–
- The tasks described in this chapter require an
EtherNet/IP network.
–
Create an RSLogix 5000 project
The example RSLogix 5000 project used in this chapter uses a
CompactLogix 5370 L3 controller.
•
Prepare the 20A-B4P2A0AYNNNC0 drive as described in Chapter 1,
PowerFlex 70 Drive Hardware on page 13
, including:
–
Mount the 20A-B4P2A0AYNNNC0 Drive
–
–
Connect the EtherNet/IP Adapter to the Drive
–
Configure the EtherNet/IP Adapter
What You Need
You need RSLogix 5000 software to complete the tasks described in this chapter.
