4.2 8000 SERIES TMR INTERFACE

LED INDICATION

Healthy

Overall health of each processor slice:
Steady green

= healthy.

Flashing green

= fault.

Active

Steady green when module is in Active mode.

Standby

Steady green when module is in Standby mode.

Educated

Steady green when module is educated.
Flashing green during module education.
Off when module is not educated.

I/O Healthy

I/O sub-system health:
Steady green

= healthy

Flashing Green = fault.

4.3 8000 SERIES TMR COMMUNICATIONS INTERFACE

LED INDICATION

Healthy

Module health.
Steady green

= healthy.

Flashing red

= fault.

Active

Steady green when module is in Active mode.

Standby

Not used.

Educated

Not used. Set to steady green at power up.

Communications

Six tri-coloured LEDs indicate data transfer activity on all
serial communication ports and both Ethernet ports.
The LEDs flash red when responding and green when
receiving.
The Ethernet LEDs indicate steady green in the absence of a
network connection.
