OPERATOR AND MAINTENANCE MANUAL
D o c N o 5 5 2 8 6 4 P a g e 4 o f 2 2
I s s u e 0 2 J u n e 2 0 0 4
1.8 MODULE REPLACEMENT CONFIGURATION
The system supports 3 forms of High Density I/O module replacement:
a. Companion slot (Hot-swap pair)
b. SmartSlot pair
c. Live insertion and removal
In the companion slot configuration, two adjacent module positions are coupled to
provide and active and standby module pair. If it intended that the system be able
to start-up (including application stop and re-start), on the primary module position,
there is no requirement to define the secondary module position.
If it is intended to allow the system to start with only the secondary module
position occupied, it is important that the module positions be included
within the system.ini file. Identical configuration settings shall be entered for
both primary and secondary module positions.
For SmartSlot pair operation, it is not possible to start-up using the “spare” module
position. The spare module position need not be in the same chassis as the
primary module position.
If it is intended to perform live insertion and removal without transfer to a standby
module no specific configuration is required. If it is intended to start-up a system
without the primary module installed in either a SmartSlot or single module live
insertion and removal configuration, the “simulate” configuration option should be
set. The simulate option will allow the system to start with these modules omitted,
the corresponding states and values being set to their fail-safe conditions.
1. A consistent module replacement philosophy should be used within any
single system. Where mixed philosophies are used, there shall be clear
indication of the repair approach applicable to each module or group of
modules.
2. In hot-swap and SmartSlot configurations, the accuracy with both
modules installed shall be within the plant required safety accuracy
specification. If tighter tolerance is required, ensure that each sensor
within a redundant configuration is allocated to independent modules and
procedural measures are implemented to ensure that only a single module
within this set of modules is paired at any instant.
3. If the SmartSlot module replacement is used, the system shall include
provision for testing the SmartSlot linking cable. This cable shall be
tested before use; the testing of this cable shall be included in the
Operating and Maintenance Manual.
4. In hot-swap configurations, a secondary module that does not pair with
the primary module in a reasonable amount of time (less than the second
fault occurrence time) must be removed.
5. In SmartSlot configurations, a secondary module that does not pair with
the primary module in a reasonable amount of time (less than the second
fault occurrence time) when the SmartSlot linking cable is installed must
be removed.
