I/O Power Supply Assembly (T8060,T8062)
P D - 6 0 5 0 M a r - 0 6
9
Output Power Terminals: TB3, TB4 (#6 screw terminals)
Terminal No. Module Slot T8200, T8202
12 6
11 5
10 4 + DC Output
9 3
8 2
7 1
6
5
4 1-6 DC Return
3 (terminals 1-6 are
2 Connected together on
1 Backplane)
Status Connectors: J14, J15
Type: 10 pin Shrouded Header, Double-Row, 0.100 x
0.100 Centers
Mfg.: AMP P/N: 102618-3
Mating Connector: AMP 87631-5
Pin Out:
Pin J14 J15
Slot Signal Slot Signal
1
2 All Input ‘A’ Fail
3 All Input ‘B’ Fail
4 All Hi Temperature
5 1 Reset 4 Reset
6 1 Power Fail 6 Reset
7 2 Reset 4 Power Fail
