I/O Power Supply Assembly (T8060,T8062)
8
Industrial Control Services
Mounting flanges can be attached to either the rear or the front of the
chassis. This allows flush mounting the chassis to a panel or mounting in a
19-inch rack.
The input crossover patch is on the T8200 chassis only.
Input Crossover Patch configured for no crossover,
source 1 and source 2 are connected to input A and
input B respectively for all modules slots. 6E5 6E6
6E7 6E8
6E3 6E4
6E1 6E2
Input Crossover Patch configured to swap source 1
and source 2 for modules slots 4 through 6. Source 1
and source 2 are connected to input A and input B
respectively for slots 1-3. Source 1 and source 2 are
connected to input B and input A respectively for slots
4-6.
Backplane Versions and Module Keying
Connector placement on AC input modules and backplanes differ from DC
modules and backplanes. This prohibits insertion of the wrong input module
type into a backplane.
Module slots in a chassis can be individually keyed to only accept a module
of an particular output voltage.
Input Power Terminals: TB1, TB2 (#8 screw terminals)
Terminal
No.
T8200 T8202 Source
1 N DC- B
2 L DC+
3 N DC- A
4 L DC+
6E6 6E5
6E7 6E
8
6E3 6E
4
6E1 6E2
