I/O Power Supply Assembly (T8060,T8062)
P D - 6 0 5 0 M a r - 0 6
7
Installation
Chassis Mounting
Figures 4 and 5 show the front and rear views of the power supply chassis.
TB3
J13
J15
TB1
J14
19"
10.5"
J1
J2
J3
J4
J6
J5
J7
J8
J12
J11
J9
J10
Input
Crossover
Patch
Figure 4. Power Supply Chassis Front View
TB4
TB2
Figure 5. Power Supply Chassis Rear View
