Installation Guide
1-2
Installing A.I. Series Software
The Setup program performs two functions. First, it uncompresses files from the
distribution disks to the destination drive and directory. Second, the Setup program
inserts registration information into the programs on the destination disk. A.I. Series
software will not run unless the registration information is inserted correctly. You
must use the Setup program to install the software correctly. The software cannot be
installed without using the Setup program.
Note
Pressing the [Esc] key at any time during the installation aborts the installation
program and returns you to the DOS prompt (after confirmation). If the master disks
were successfully processed before the full install was aborted, use the Update option
to complete the installation, instead of attempting another full installation.
To install the A.I. Series software:
1. Insert the Setup disk into your floppy drive.
2. Start the Setup program.
•
Type: A: [Enter] (Use the appropriate drive letter for your system.)
•
Type: SETUP [Enter]
You will see the following screen.
