Chapter 5
Creating and Editing Fonts
5–7
Pixel Color
Pixel color affects the auto teach function, and also manual placement of
pixels within the character pattern.
AUTO MANUAL
✓ Green Yellow Only places green pixels
in character. Place green anywhere.
✓ Green Yellow Places only yellow pixels
around character. Place yellow anywhere.
✓ ✓ Green Yellow
Places both green and
yellow pixels. Place green in black.
Place yellow in white.
Green Yellow Clears all pixels in auto
teach mode. Erase individual pixels.
G -
Reduces the number of green pixels by increasing the G Thin value and
re-teaching the character. The G Thin value can be increased up to 5.
Y -
Reduces the number of yellow pixels by increasing the Y Thin value and
re-teaching the character. The Y Thin value can be increased up to 5.
G +
Increases the number of green pixels by decreasing the G Thin value and
re-teaching the character. The G Thin value can be decreased down to 1.
Y +
Increases the number of yellow pixels by decreasing the Y Thin value and
re-teaching the character. The Y Thin value can be decreased down to 1.
Arrow Keys
Use the arrow keys to make fine adjustments to the placement of the
character box.
Done
Exits to the Edit Font panel.
