Bulletin 2097 Memory Module Programmer 7
Publication 2097-QS001D-EN-P - November 2011
Switch On/Off Memory Module Programmer
Switch On
Step
Display
Press .
The following is displayed in sequence.
EPM PROGRAMMER
The parameter version that the memory module programmer is configured with (for example,
400) is displayed.
INTERN CFG 400
The parameter version of the memory module (for example, 400) plugged into the master port
is displayed.
MASTER CFG 400
The name of the parameter file (for example, DEFAULTS) stored in the memory module plugged
into the master port is displayed.
MSTFILE#DEFAULTS
If no memory module is plugged into the master port, this message is displayed.
MASTER MISSING!
TIP
After the initialization, the main menu shown last is automatically called up.
Switch Off
Step
Displayed
Press
.
The shutdown process takes 5 seconds.
If you press any key within these 5 seconds, the shutdown process is aborted.
SHUTDOWN.. 5SEC
TIP
The memory module programmer automatically turns off after 5 minutes, if no operation
takes place during this time.
ON
OFF
