Chapter 4 Analyzing Reports
Object
Type
Description
each Operation of each Unit Procedure in the batch.
Batch Alarm Summary
Text
Shows alarm information, including the time the alarm event occurred (Event Time), whether
the alarm was acknowledged, the alarm description, and the Unit and Phase in which the alarm
occurred.
Operator Prompt Summary Text
Shows operator prompt information, including the time the prompt occurred and was
completed (Prompt Time and Prompt Completed Time), the prompt's description, and the Unit
and Phase in which the prompt occurred.
Operator Comments
Summary
Text
Shows operator comment information, including the time the operator entered the comment,
the Area and MachineID from which the operator entered the comment, the UserID of the
operator, and the actual comment.
Unit Procedure Details
Text
Shows the Name, Start Time, and End Time of each Unit Procedure that ran under the selected
Batch ID.
Parameter Information
Text
Parameter information, including the Parameter name and Value, the time the parameter was
encountered, and the Phase, Operation, Unit Procedure, and Unit on which the batch was
operating when the parameter was encountered.
Report Information
Text
Report Parameter information, including the Parameter name and Value, the time the
parameter was encountered, and the Phase, Operation, Unit Procedure and Unit on which the
batch was operating when the parameter was encountered.
Batch Trend
Graphic Trend of a continuous reporting tag, such as temperature, pressure, flow rate, or other.
The Batch Compare report allows you to select and compare batch
information from up to three batches. By default, the report includes
the following:
• Recipe, Area, Unit, Start Time, End Time, Batch Duration,
and Completion State.
• Three Time-series trends.
When you switch from Design mode to Preview mode, the Batch
Compare report displays information based on the master recipe or
the Batch ID specified in the Report Configuration Selection.
You can select up to three batches to compare in the Report
Configuration Selections. To select multiple batches, use the Shift
Batch Compare Report
Selecting Data to Display on
the Batch Compare Report
56
