6 FLEX Ex Redundant ControlNet Barrier Module
Publication
1797-5.35 - July 2004
Installation in Zone 2
This 1797-BCNR must not be exposed to the environment. This barrier
module has a protection factor of IP20. Mount the 1797-BCNR inside an
enclosure with a protection class IP54.
Installation in Zone 22
When the 1797-BCNR is installed in Zone 22, the following cabinets must be
used: IVK2-ISRPI-V16LC; IVK2-ISRPI-V8HYW; or IVK2-ISRPI-V8LC.
These cabinets can be purchased from:
Pepperl+Fuchs GmbH
Konigsberger Allee 85-87, D-68307
Mannheim, Germany
Attn: PA Sales Dept.
Kirsten Becker
Telephone +49 776 1298
www.pepperl-fuchs.com
The IS-RPI cabinets (type IVK2-ISRPI-V8LC, IVK2-ISRPI-V8HYW, or
IVK2-ISPRI-V16LC) ensures the basic protection for the intrinsically safe
apparatus of the IS-RPI system for use in Zone 22. It corresponds with
category 3D according to RL 94/9 EG and with the type label marked with
the following information:
Pepperl+Fuchs GmbH
68301 Mannheim
IVK2-ISRPI-V8LC (or IVK2-ISRPI-V8HYW or
IVK2-ISRPI-V16LC)
II 3D IP54 T 70°C
CE
Serial (manufacturing) number
Model Year
