12 FLEX Ex Redundant ControlNet Barrier Module
Publication
1797-5.35 - July 2004
1797-BCNR Specifications
Transmission Rate
5 Mbit/s
Transmission Attenuation
-7.84dB
Weight
Approximately 200g
Dimensions
3.94 in.(w) x 3.55 in.(d) x 2.76 in.(h)
10cm(w) x 9cm(d) x 7 cm(h)
Operating Temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20 to 70
o
C (-4 to 158
o
F)
Storage Temperature
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry
Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating
Thermal Shock):
-20 to 100
o
C (-4 to 212
o
F)
Relative Humidity
IEC 60068-2-30 (Test Db, Un-packaged Non-operating
Damp Heat):
5 to 95% non-condensing
Shock
IEC60068-2-27 (Test Ea, Unpackaged shock):
Operating 30g
Non-operating 50g
Vibration
IEC60068-2-6 (Test Fc, Operating):
5g @ 10-500Hz
Emissions
CISPR 11:
Group 1, Class A
ESD Immunity
IEC 61000-4-2:
8kV indirect discharges
Radiated RF Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to
2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity
IEC 61000-4-4:
±2kV at 5kHz on communications ports
Surge Transient Immunity
IEC 61000-4-5:
±2kV line-earth(CM) on shielded ports
