Rockwell Automation 1797-BCNR FLEX Ex Redundant ControlNet Barrier Module User Manual
Page 15
FLEX Ex Redundant ControlNet Barrier Module 15
Publication
1797-5.35 - July 2004
1797-BCNR
1797-BCNR
ControlNet Ex
Redundant Media
Adapter
Allows connection between a
ControlNet system and a
ControlNet Ex system
CNet Ex Tap Trm 1797-TCAP
ControlNet Ex Tap
(Dummy) Terminator
Represents one ControlNet Ex
node and is a simple capacitor
(56pF) with a coax connector
ControlNet Ex
Tap
1797-TPx
ControlNet Ex Coax
Tap
Four types of connections
available: S (straight t-tap), R
(right angle t-tap), YS (straight
y-tap), and YR (right angle
y-tap) - a maximum of 48 taps
can be connected together by
coax trunk cable
CNet Ex Trk Trm
1797-XT
ControlNet Ex Trunk
Terminator
Simple resistor (75
Ω) with
coax connector that must be
on each end of the ControlNet
Ex coax trunk for termination
Coax Trunk Cable 1797-RG6
Quad-Shield, RG-6
75
Ω Coax Trunk
Cable
Maximum (functional) length
between 2 1797-TPx is 3280ft
(1000m) - each 1797-TPx
reduces the (functional) coax
cable length by 53.4ft (16.3m)
None
None
Standard Coax Trunk
Cable BNC Couplers
Different standard cable
couplers, 90
o
, 180
o
, etc.
System
Diagram Name
Catalog
Number
Catalog Name
Description
