1Ć3
1.2 Related Hardware and Software
The 2ĆIn/2ĆOut 4Ć20mA Analog Rail module, M/N 61C351, contains
the following:
1. One 2ĆIn/2ĆOut 4Ć20mA Analog Rail module
2. One I/O Rail cable: M/N 45C5
3. Two plug connectors: 12Ćpoint connector part no. 419434Ć2R
ă4Ćpoint connector part no. 419434Ć1R
4. One .25A fuse (installed in the module): part no. 64676Ć23J
5. One .75A fuse (required for operation on 24 VDC):
part no. 64676Ć23Q
6. Two cable retainer clips
7. Two 32mA fuses (installed in the module): part no. 64676Ć44A
8. Two spare 32mA fuses: part no. 64676Ć44A
The Analog Rail module can be configured with the hardware
(purchased separately) listed in figure 1.1.
Host Model Operating Mode
DCS 5000/AutoMax
Remote I/O Head
M/N 57C330 Local Head
AutoMate 20, 20E
M/N 45C20, 45C21,
45C220, 45C221,
45C224, 45C225
Local Head or Rail *
AutoMate 30, 30E
M/N 45C301, 45C305,
45C307
Local Head or Rail *
AutoMate 40, 40E M/N 45C410, 45C411 Local Head or Rail *
AutoMate Local
I/O Processor
M/N 45C200B
(and later versions)
Local Head
AutoMate
Remote I/O Head
M/N 45C37, 45C38 Local Head
Power Module
Interface Processor
B/M 60000 Rail
* Direct connection to the Processors (Local Head mode) or connection
through an AutoMate Local I/O Head, M/N 45C22, 61C22, 61C22A, or
61C23 (Rail mode). Note that it is also permissible to configure the Analog
Rail module for Rail mode even if it is connected directly to an AutoMate
20, 30, or 40 Processor.
Figure 1.1 Ć Analog Rail Module Hardware Configuration
