Publication 2090-IN004B-EN-P — June 2008
External Shunt Modules 13
Install the External Shunt
Module These procedures assume you have prepared your mounting panel
and understand how to bond your system components.
Mount the External Shunt Module
Follow these steps to mount your external shunt module.
1. Lay out the position for your shunt module.
Refer to Establishing Noise Zones , beginning on page 6 , for
panel layout recommendations. Refer to Product Dimensions ,
beginning on page 14 , for locating the mounting holes.
2. Attach the shunt module to the cabinet by using M6 (0.25 in.)
bolts.
Make sure all fasteners are properly bonded to the subpanel.
3. Tighten all mounting fasteners.
IMPORTANT
To improve EMC performance, mount the module on the same
panel as the drive and as close to the drive as possible.
