Specifications – Rockwell Automation 2711P-RDT12H High-bright Display Module User Manual
Page 25
High-bright Display Modules 25
Publication 2711P-IN026E-EN-P - September 2008
Specifications
PanelView Plus or PanelView Plus CE Terminal with High-bright Display
Module - 2711P-RDT12H
Attribute
Value
Display
Display type
Color active matrix, thin film transistor (TFT) liquid crystal
display (LCD)
Display size
12.1 in.
Display area (W x H)
246 x 184 mm (9.7 x 7.2 in.)
Display resolution
800 x 600
Luminance
1000 cd/m
2
(Nits)
Backlight
Not replaceable
Touch screen
Analog resistive
Electrical
Input voltage, DC
24V DC nom (18… 32V DC)
Power consumption, DC
70 W max (2.9 A @24V DC)
Mechanical
Dimensions, (HxWxD) approx. for based configured unit without communication module
1250 high-bright touch
282 x 363 x 74 mm (11.12 x 14.30 x 2.90 in.)
Weight for base configured unit without communication module
1250 high-bright touch
3.2 kg (7.1 lb)
General
Battery life
4 years min. at 25 °C (77 °F)
Clock
Battery-backed, ±2 minutes per month
Status indicators
COMM (green), Fault (red)
External CompactFlash storage
512 MB max
