High-bright Display Modules 15
Publication 2711P-IN026E-EN-P - September 2008
Logic Module Compatibility
The high-bright display module is only compatible with the following DC logic
modules.
The high-bright display module is not compatible with AC logic modules catalog
number 2711P-RPxAx.
PanelView Plus and PanelView Plus CE Logic Modules
Cat. No. Description
PanelView Plus or PanelView Plus CE 700 to 1500 Logic Modules (1)
(1) These logic modules are compatible with any of the 2711P-RWx internal CompactFlash cards.
2711P-RP Logic module without flash/RAM memory, DC input
2711P-RPD Logic module without flash/RAM memory, isolated DC input
PanelView Plus 700 to 1500 Logic Modules
2711P-RP1 Logic module with 64 MB flash/64 MB RAM, DC input
2711P-RP1D Logic module with 64 MB flash/64 MB RAM, isolated DC input
2711P-RP2 Logic module with 128 MB flash/128 MB RAM, DC input
2711P-RP2D Logic module with 128 MB flash/ 128 MB RAM, isolated DC input
2711P-RP2DK Conformal-coated logic module with 128 MB flash/128 MB RAM, isolated DC input
2711P-RP2K Conformal-coated logic module with 128 MB flash/128 MB RAM, DC input
2711P-RP3 Logic module with 256 MB flash/256 MB RAM, DC input
2711P-RP3D Logic module, 256 MB flash/256 RAM, isolated DC input
PanelView Plus CE 700 to 1500 Logic Modules
2711P-RP6 PanelView Plus CE logic module with 128 MB flash/128 MB RAM, DC input
2711P-RP6D PanelView Plus CE logic module with 128 MB flash/128 MB RAM, isolated DC input
2711P-RP6K PanelView Plus CE conformal-coated logic module with 128 MB Flash/128 MB RAM, DC input
2711P-RP6DK PanelView Plus CE conformal-coated logic module with 128 MB flash/128 MB RAM, isolated
DC input
2711P-RP7 PanelView Plus CE logic module with 256 MB flash/256 MB RAM, DC input
2711P-RP7D PanelView Plus CE logic module with 256 MB flash/256 MB RAM, isolated DC input
